Tell us what you want to store. We will help you choose.
Measure & choose
What type of vehicle do you have?
Campervans and motorhomes have different storage spaces. Select your vehicle for the right measuring instructions.
All dimensions are overall external dimensions.
The dimensions in our webshop are the module’s overall external dimensions, including protruding parts such as runners and handles. You do not need to add anything. Compare these dimensions with the available space in your vehicle.
Also check that the complete module fits through the clear height and width of your door opening.
Measuring your campervan
Measure where your module will go.
All dimensions are overall external dimensions.
The dimensions in our webshop are the module’s overall external dimensions, including protruding parts such as runners and handles. You do not need to add anything. Compare these dimensions with the available space in your vehicle.
Also check that the complete module fits through the clear height and width of your door opening.
Note the available length, width and height in centimetres. These photos show you which space to include.
1. Length to the closed rear doors
Measure from the far end of the storage space to the inside of the closed rear doors.Do not stop measuring at the edge of the floor.Include the space beyond the floor edge: this is often where the handle sits.
Measure one total length, including the space beyond the floor edge.
2. Width where the module will go
Measure the clear width between cupboards or other obstructions where you want to fit the module.
3. Height where the module and boxes will sit
Measure from the floor to the underside of the bed, where the module and boxes will sit and move.
A bed support at the side does not necessarily limit the height.In this example, there is a 5 cm space between the cupboard and the boxes for the aluminium frame and runners. This can allow the boxes to pass a protruding bed support. Check whether the support actually gets in the way.
The position of the bed support determines whether it obstructs the module or boxes.
Not sure whether a bed support or cable duct is in the way? Send us a photo and your measurements. We will help you check.
Measuring your motorhome
The measurements depend on your module.
All dimensions are overall external dimensions.
The dimensions in our webshop are the module’s overall external dimensions, including protruding parts such as runners and handles. You do not need to add anything. Compare these dimensions with the available space in your vehicle.
Also check that the complete module fits through the clear height and width of your door opening.
Follow the dimension options on your system’s product page. The garage opening height and the internal height needed for a bracing kit are different measurements.
Double module with bracing kit
This option requires two internal height measurements:at the door endandat the middle of the planned module. At both positions, measure from the finished garage floor to the ceiling. Do not measure the door opening or start from the threshold.
This is why we ask for two heights.The surface against which the bracing legs rest may be at a different height at the door end and in the middle of the module. Measure at both positions from the finished garage floor to the surface against which the leg will rest.
Triple module: measure the door opening first
Measure the clear height and width of your garage door opening.
The overall external dimensions of your chosen triple module must fit through the door opening. You can assemble the module outside the motorhome and then place it inside as a complete unit.
Triple module with bracing kit
You do not need to provide extra internal garage heights for the bracing kit: it is supplied long enough as standard. You still need to select the garage opening height for the module itself.
Threshold and mounting configuration
The threshold is the raised edge at the garage door. If it is higher than the garage floor, the slide must be able to move freely over it when extended.
How do you measure the threshold?
Measure inside the garagevertically from the finished floor to the top of the threshold, where the module slides out. This is the threshold height. Do not measure from the ground outside the motorhome.
Double slide-out modules for motorhomes
For these modules, select the installation height:standard, 2–6 cm threshold or 6–9 cm threshold. We adapt the configuration to your selected threshold height so the slide can clear it. There isno extra charge.
Standard slide-out trays and table and chair holders for motorhomes
Here you choose a mounting frame. The frame provides a fixed, aligned base and makes installation easier.
Without a frame:a lower overall height, but installation requires more precision. Check that the slide can clear the threshold.
Standard frame:for a threshold up to 5 cm. Surcharge €40.
Raised frame:for a threshold up to 8 cm. Surcharge €40.
The 5 and 8 cm measurements refer to the threshold heights these configurations can clear. They are not heights to add to the product dimensions.
One-handed operation is a separate €25 option.It is not included with the frame. Without a frame, it is fitted in reverse to provide sufficient clearance.
A different module or an unusual threshold?
Configurations vary by system. Use the options on your module’s product page. If your threshold falls outside the listed heights, or you are unsure which option to choose, send us a photo and the measured threshold height.
Need help deciding which module fits your garage? Share your vehicle details, photos and measurements with us.
Personal advice
We will help you choose.
Tell us your camper type, the available dimensions and what you want to store. Bjorn will help you choose a suitable configuration or a made-to-measure solution.
Our modules are supplied as a practical flatpack system. You only need to fit a few bolts; fixings are included with the featured double module.
Processing and production: 3 working days after payment is received. GLS transit: 2–4 working days. Total estimated delivery time: 5–7 working days, Monday to Friday. Order cut-off: 14:00, Brussels time (Europe/Brussels). Orders placed after this time are processed from the next working day. Shipping is €45 per order, including orders with multiple modules. When paying in another currency, checkout shows the converted shipping charge.
Choose your operation
One hand or two.
With the standard configuration, you operate the locking mechanism with two hands. The one-handed version has a linked mechanism and costs an extra €50.
The threshold is the raised edge at the garage door. Inside the garage, measure vertically from the finished floor to the top of that edge, where the module slides out. This tells us the height the slide needs to clear.
Choose standard, 2–6 cm threshold or 6–9 cm threshold to suit your garage. There is no extra charge for this choice on this module.
Unsure which configuration to choose, or is your threshold outside these heights? Contact us before ordering.
Additional mounting option
Add a bracing kit?
For this double motorhome module, you can add a bracing kit for €50. Enter the internal garage height at the door end and at the middle of the module. Both heights are required for this configuration.
This is why we ask for two heights.The surface against which the bracing legs rest may be at a different height at the door end and in the middle of the module. Measure at both positions from the finished garage floor to the surface against which the leg will rest.
If you are unsure, let us check which mounting method is suitable for your garage first.
